Ubiquiti USW-WAN-RJ45 UniFi 10GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP

https://citytechnology.com.au/web/image/product.template/22509/image_1920?unique=aa5dc7b

Product Code: USW-WAN-RJ45

$ 497.42 incl. GST 497.42 AUD $ 497.42

$ 439.00

    This combination does not exist.

    Add to Cart
    Ubiquiti
    Ubiquiti

    Ubiquiti Inc offers a broad and expanding portfolio of networking products and solutions for service providers and enterprises. Their service provider product platforms provide carrier-class network infrastructure for fixed wireless broadband, wireless backhaul systems and routing. Their enterprise product platforms provide wireless LAN infrastructure, video surveillance products, switching and routing solutions and machine-to-machine communication components. Ubiquiti Networks believes that their products are highly differentiated due to proprietary software protocol innovation, firmware expertise, and hardware design capabilities.

    Terms and Conditions
    100% Original
    Fast Delivery

    Share this product:


    Ubiquiti USW-WAN-RJ45 UniFi 10GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP

    Product Code: USW-WAN-RJ45

    Unifi 10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.

    Combine with Shadow Mode High Availability to ensure uninterrupted connectivity

    (1) 10 GbE ISP uplink and (2) 10 GbE downlink ports

    (2) AC inputs for power redundancy

    (1) GbE port for management with UniFi Network

    *Use an additional USW-WAN-RJ45 switch for ISP failover deployments.

    Technical Specifications
    Overview
    Dimensions
    442.4 x 120 x 43.7 mm (17.4 x 4.72 x 1.7")
    Port Layout
    1 GbE RJ45
    1 (1G/100M/10M)
    10 GbE RJ45
    3 (10G/5G/2.5G/1G/100M)
    Redundancy
    (2) AC inputs
    Form Factor
    Rack mount (1U)
    Performance
    Switching Capacity
    20 Gbps
    Total Non-Blocking Throughput
    10 Gbps
    Forwarding Rate
    15 Mpps
    Hardware
    Max. Power Consumption
    18W
    Power Method
    (2) Universal input, 100—240V AC, 50/60 Hz
    Power Input Method
    AC input
    Power Supply
    (2) AC/DC, internal, 36W
    Supported Voltage Range
    100—240V AC
    Management
    Ethernet
    Weight
    Without mounting brackets: 2.3 kg (5.1 lb) With mounting brackets: 2.4 kg (5.3 lb)
    Enclosure Material
    SGCC steel
    Mount Material
    SGCC steel
    ESD/EMP Protection
    Air: ± 16kV, contact: ± 10kV
    Ambient Operating Temperature
    -5 to 40° C (23 to 104° F)
    Ambient Operating Humidity
    10 to 90% noncondensing
    LEDs
    Ethernet
    Yes
    System
    Yes
    Certifications
    CE, FCC, IC
    NDAA Compliant
    Yes
