    Tycon Power TP-DCDC-4848G-HP 36-72VDC IN 56VDC OUT, 50W DC to DC Converter


    The TP-DCDC-4848G-HP DC to DC converters offered by Tycon Power Systems are a low cost and high reliability solution for those requiring 48VDC Power Over Ethernet voltage from a +/-48V battery system.

    The Tycon Power TP-DCDC-4848G-H have an integrated Gigabit Passive PoE injector to apply the regulated 48VDC to the CAT5 Ethernet cable. The input voltage must be between 36VDC and 72VDC.

    Tycon Power TP-DCDC-4848G-H accepts data-in to a shielded RJ45 Jack and provide data-out and PoE power on the shielded RJ45 output jack.

    They work by supplying power on the Ethernet pins 4,5(V+) and 7,8(V-).

    Tycon Power have various protections for surge, short circuit and overload. The units have power output of 50W.


    Tycon Power TP-DCDC-4848G-HP Features:

    • Input Voltage +/- 36-72VDC; Output 48VDC Passive PoE
    • Integrated Gigabit PoE Inserter
    • High Power 50W
    • Short Circuit, Over Current and Over Voltage Protection
    • High Temperature Operation 60°C

    Dimensions: 85 x 76 x 36mm

    Weight: 134g
