Tycon Power TP-DCDC-2456GD-BT 18-36VDC IN 56VDC OUT 70W 4Pair Hi Power


Product Code: TP-DCDC-2456GD-BT

Barcode: 1PTP-DCDC-2456GD-BT

337.70 incl. GST 337.7 AUD 337.70


    This combination does not exist.

    Add to Cart

    Tycon Power
    Tycon Power

    Tycon Power Systems designs and manufactures turnkey remote power systems utilizing solar and wind power and accessories including a variety of unique PoE and power conversion products. Tycon Power® products include; industrial strength outdoor PoE switches, midspan power inserters, PoE surge protection, DC to DC converters, and a large selection of accessories.

    100% Original
    Fast Delivery

    Share this product:

    Tycon Power TP-DCDC-2456GD-BT 18-36VDC IN 56VDC OUT 70W 4Pair Hi Power

    18-36VDC IN, 56V 70W 802.3bt PoE OUT. DC to DC Converter and 5G 802.3bt PoE Injector


    • Input Voltage 18VDC to 36VDC

    • 8 wire (4 Pair) 56VDC 802.3bt PoE Output

    • High Power Output to 70W

    • Dual DC Inputs for Connecting 2 Power Sources

    • Gigabit Data Throughput

    • Low Voltage Disconnect Feature

    • Short Circuit, Over Current and Reverse/Over Voltage Protection

    • Industrial Temperature Range -40 to 70C


    • 24VDC Remote Power Systems

    • 48VDC or -48VDC Remote Power Systems

    • 802.3bt PoE 4 Pair Powered Cameras and Radio’s

    • 802.3at PoE Powered Devices

    The Gigabit compatible TP-DCDC-2456GD-BT is 802.3at/bt compatible high power DC to DC converters/PoE inserters designed for operation in industrial environments. The inserter conforms to the new IEEE802.3bt Power Over Ethernet standards for industry compatibility. The PoE inserter supplies 56VDC PoE power on all 8 Ethernet wires (4 Pair). They are backward compatible with 802.3at so they will safely power 802.3at and 802.3af devices in addition to the new 802.3bt devices. The TP-DCDC-2456GD-BT is a low cost option for applications with 18-36VDC available. The input and output are isolated so they work in a negative ground or positive ground system. They have two DC inputs for connecting 2 power sources, like a primary and backup power source. They have various protections for low voltage, surge, short circuit and overload.
