Tycon Power TP-DC-2448GDx2-HP Gigabit Dual Output 802.3at PoE Injectors 18-36V
Tycon Power 18-36VDC IN. Two 802.3af/at output ports with Gigabit data passthrough. Powers two PoE devices from a single 24VDC voltage source. Part Number: TP-DC-2448GDX2-HP
Features
• Input Voltage 24VDC
• Dual 802.3af/at outputs
• High Power Output to 70W
• Surge Protected to 15kV
• Dual DC Inputs for Connecting 2 Power Sources
• 10/100/1000 Data Compatibility, Shielded Connectors
• Short Circuit, Over Current and Reverse/Over Voltage Protection
• Industrial Temperature Range, DIN Rail Mountable
Applications
• 24VDC Remote Power Systems running on batteries
• Power a Camera and Wireless using a single PoE Injector
• Power a Wireless AP and Backhaul using a single PoE injector
• PoE Lighting Applications
The TP-DC-2448GDX2-HP is a unique high power PoE injector with Dual 802.3af/at compatible outputs. This means that two devices can be powered from a single PoE injector. The data path between the devices is handled by the injector so no PoE switch is required.
They have two DC inputs for connecting 2 power sources, like a primary and backup power source. They have various protections for short circuit, overload and surges caused by ESD or lightning. The built-in surge protection protects sensitive connected devices from damage due to surges on data and PoE lines. All 8 wires are protected.
The input voltage and output voltage are isolated to avoid any grounding or negative voltage issues.
