PolyPhaser IS-50NX-C0 Type N F/F RF Surge Protector
Product Code: IS-50NX-C0
Coaxial RF surge protector with blocking capacitor and gas discharge tube for RF installations requiring DC blocking.
Specifications
- Frequency range: 1.5–700 MHz
- Impedance: 50 Ω
- Connectors: N female to N female
- DC handling: DC block
- Maximum input power: 2 kW
- Surge current: 50 kA (8/20 μs)
- VSWR: ≤ 1.1:1
- Insertion loss: ≤ 0.1 dB
- Dimensions: 62.23 × 44.45 × 38.10 mm
- Weight: 158.76 g
- Operating temperature: −50 to +50 °C
- Compliance: CE, RoHS, UL497E
Datasheet source: PolyPhaser IS-50NX-C0 Rev 1.1.
