Cambium Networks C058940A821A ePMP 4500 5 GHz 8x8 Access Point Radio (ROW) (ANZ cord)

Cambium Networks C058940A821A ePMP 4500 5 GHz 8x8 Integrated Access Point Radio

ePMP 4500 Series 5 GHz Fixed Wireless Access Point

Cambium Networks’ ePMP product line has set the standard for high performance, scalability and reliability in harsh interference environments, all at a compelling price. ePMP 4500 access points (AP) interoperate with Force 400 Subscriber modules and support backward compatibility to Force 300 Subscriber modules. A sophisticated scheduling and QoS engine combined with TDD synchronization allows ePMP 4500 APs to deliver consistently high-quality service plans to a large number of end users.

All ePMP 4500 Access point series are managed with cnMaestro™, and networks can be planned with LINKPlanner.

 ePMP 4500 8x8

The ePMP 4500 delivers up to 4 Gbps and supports up to 120 subscriber modules. Featuring 8x8 MU-MIMO, the 5 GHz ePMP 4500 can transmit to four Force 400 SM’s at the same time. This effectively quadruples the capacity of 2x2 systems and in the process, increases link budgets by 6 dB with downlink beamforming. The ePMP 4500 has an integrated 90º 8x8 MU-MIMO sector antenna. With TDD synchronization, ePMP 4500 networks can scale to thousands of end users leveraging a small number of channels.

Key Specifications

• High-performance, scalable and reliable access points for fixed wireless broadband

• Features MU-MIMO for up to 4 Gbps in 5 GHz

• Low TCO with three-year hardware warranty

• Interoperable with all Force 4500 radios

• Cloud or on-premises network management with cnMaestro

• Antenna Integrated 8x8 MU-MIMO 90º Sector 17 dBi gain

• Environmental IP67

• Input Voltage 44V to 59V

• Power Consumption 32W Maximum

• Dimensions (H x W x D) 643 x 487 x 157 mm

• Channel Width 20 | 40 | 80 MHz

• Frequency Range Wide Band Operation 4910–6135 MHz

High-performance, scalable and reliable access points for fixed wireless broadband

ePMP 4500 features MU-MIMO and up to 4 Gbps in performance

Low TCO with three-year hardware warranty

Interoperable with all Force 400 and Force 300 Subscriber Modules
